MACHINERY PARK

PIPE

BRUECKMAN 3D SCANNER

The 3D scanner is used for obtaining the X, Y, Z coordinates and solid models of the products.



CNC LATHE

Pipes, edges, unions and valves are processed in CNC lathes during our machining.



PIPE EDGE SHAPING

Shaping is performed for the pipe edges and these are later sent to the CNC bending machine or the bending robot. This machine has 5 stations.



ROBOT PIPE BENDING

Shaping operations for pipes with external radiuses up to 25 mm are made as Robot.



CNC PIPE BENDING

Shaping operations for pipes with external radiuses up to 25 mm are made as CNC.

HOSE

CNC LATHE

Hose, edges, unions and valves are processed in CNC lathes during our machining.



HOSE CUTTING

Lengthwise hose cutting and peeling operations are performed.



HOSE EXTRUSION PRESS

Extrusion operation is performed for hoses up to 2”.

HOSE TEST DEVICE

Manufactured hoses are subjected to blasting test using water up to 1500 bars. Furthermore, air tightness test is performed in our company with 100 bars of air.



HOSE TEST DEVICE

Manufactured hoses are subjected to blasting test using water up to 1500 bars. Furthermore, air tightness test is performed in our company with 100 bars of air.

PUMP

SOLIDWORK CAD CAM

The production phase is started pursuant to the drawing of the incoming samples by using the Solidworks Cad Cam software.



CNC VERTICAL PROCESSING CENTER

The pump parts are processed in the CNC vertical processing center and thereafter sent to the assembly line.



CNC LATHE

Pump, edges, unions and valves are processed in CNC lathes during our machining



HONING MACHINE

Internal radius sensitive honing operation is performed for the pump parts. The sensitivity of this machine is between 0,002 and 0,008.



LABORATORY

LABORATORY - 1

LABORATORY - 2

LABORATORY - 3

LABORATORY - 4

LABORATORY - 5
